Business Unmanaged Switch S1000-16TP2S
16*10/100/1000 Base-T ports(POE/POE+)
2* 1000 Base-X SFP ports
IEEE 802.3af/at
Total Output Power:250W.
16-Port Gigabit Unmanaged POE Switch
Product Features:
- Support IEEE802.3at standard, compatible with IEEE802.3af powered device (PD).
- With VLAN functions.
- Automatic detection of PD equipment.
- The output power of a single port can reach up to 30W.
- Automatic detection and identification of standard PoE power receiving equipment, intelligent power supply, will not burn non-standard PoE power receiving equipment or ordinary equipment.
- Support IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control.
- Panel indicator lights monitor working status and help failure analysis.
Description
Product Description:
S1000-16TP2S is a full Gigabit unmanaged PoE switch independently developed by TG , with 16 Gigabit adaptive RJ45 ports, 2 Gigabit SFP fiber module slots. Each RJ45 port supports MDI/MDIX auto flip and wire-speed forwarding functions. Ports 1-16 have PoE power supply function, support IEEE802.3af/at standard, can be used as Ethernet power supply equipment, can automatically detect and identify the power receiving equipment that meets the standard, and supply power to it through the network cable.
11-inch standard rack installation, plug and play, no management, convenient and fast. With PoE disconnected automatic connection function (the switch PoE port is disconnected and automatically connected), with a one-key VLAN function, users can choose to open or close according to different application environments.
Product Specifications (POE):
| Product Features | Product Model : S1000-16TP2S |
|---|---|
| Hardware Specifications: | |
| Fixed Ports | 16*10/100/1000 Base-T ports(POE/POE+) 2* 1000 Base-X SFP ports |
| Max Output Power(single port) | 30W |
| Total Power Consumption | 300W |
| PoE Pin-out | 1/2(+),3/6(-) |
| Switching capacity | 36Gbps |
| Forwarding Rate | 27Mpps |
| Temperature | Operating temperature: (0 - 40)°C Storage temperature: (-40 - 70)°C |
| Humidity | Operating humidity: (10% - 90%) RH, non-condensing Storage humidity: (5% - 90%) % RH, non-condensing |
| Dimensions(L*W*H) | 440(L)*208(W)*44(H)mm |
| Power | AC:100～240VAC,50～60Hz |
| Power consumption | 250W output the whole device |
| Weight | <4.2Kg |
| Lightning protection | 4KV |
| MAC address table | 8K |
| LED Indicator | Power, Link/Act, POE |
| Software Specifications: | |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3af, IEEE 802.3at |
| Forwarding mode | Store-and-forward |
| Other functions | VLAN isolation |
