Campus Managed Switch ES2010M-8T2SFP
Roll over image to zoom in
8*10/100/1000BASE-T Ports
2*1000BASEX SFP Ports,(AC)
Product Features:
- Optical port uplink: independent SFP optical port with long-distance interconnection mechanism.
- Port buffer: The port buffer is large, and video storage is not congested.
- Data control: Supports 802.3X full duplex flow control and network storm suppression.
- Redundant network: Supports STP/RSTP/MSTP, industrial ERPS ring network function, ensuring network stability.
- Multicast management: Supports IGMP Snooping V1/V2/V3.
- VLAN: Supports IEEE 802.1Q VLAN, effectively isolating broadcast domains.
- QOS: Supports COS \ DSCP, 4 queues, and supports WRR \ SP scheduling mode.
- Security management: Supports ACL access control lists, 802.1X, and hierarchical user management.
- Management function: Supports CLI, WEB, and SNMP management.
- Monitoring and maintenance: supports port mirroring, interface status monitoring, and log management.
Product Overview:
ES2000M series is the latest development of Gigabit speed managed Ethernet switch that is especially for SMB (Small Business) market. Besides high-performance access, it also offers abundant security access policy control and enhanced network manageability and maintenance. This makes it ideal for network construction on industries such as government, small to midsize enterprise, school and hotel.
Specifications:
| Product Features | Product Model :ES2010M-8T2SFP |
|---|---|
| Switching capacity | 20Gbps |
| Packet forwarding rate | 15Mpps |
| Management port | 1 Console Port |
| RESET Button | 1 RESET Button |
| 10/100/1000 Base-T port | 8 |
| 1000 Base-X port | 2*SFP |
| Fan NUM | Fanless |
| PoE+ | - |
| Input voltage range | AC: 100V～240V,50/60Hz |
| Temperature | Operating temperature: (-10 - 50)°C Storage temperature: (-40 - 70)°C |
| Humidity | Operating humidity: (10% - 90%) RH, non-condensing Storage humidity: (5% - 90%) % RH, non-condensing |
| Dimensions (W × D x H) | 270×190×44mm |
| Weight | ≤1.5 kg |
| MAC | 8K |
| Jumbo frame | 10240 |
| Buffer | 4.1M |
| Copper port features | Half-duplex, full-duplex, auto-negotiation MDI/MDI-X |
| Ethernet Functions | Static configuration and dynamic MAC learning Configurable aging time of the MAC address Port mirror Link aggregation (up to 8 ports per group) IEEE 802.3ad(Dynamic link aggregation), static port aggregation Support outbound and inbound port speed limit LLDP Energy saving |
| VLAN | 802.1Q (up to 4K VLAN) Manage VLAN MAC based VLAN IP subnet based VLAN Voice VLAN GVRP |
| Spanning Tree | STP/RSTP/MSTP STP Root Guard BPDU Guard Loop Guard |
| DHCP | DHCP Snooping |
| Multicast | IGMP V1/V2/V3 Snooping IPv4/IPv6 Multicast VLAN MLD v1/v2 Snooping |
| QoS | Diff-Serv QoS SP+WRR/WFQ/DRR 802.1p, DSCP priority mapping CoS-Queue Map DSCP-CoS Map |
| ACL | Access list based on Source MAC Access list based on Destination MAC Access list based on Source IP Access list based on Destination IP Access list based on Source Port Access list based on Destination Port Access list based on Time |
| IPv6 | IPv6 Ping, IPv6 Telnet MLD Snooping |
| Security | Hierarchical user management and password protection Storm suppression for unknown Unicast, multicast, multicast, broadcast type Port isolation ARP Binding Configure max num of dynamic arp Support port-based 802.1X local authentication Support Radius authentication Support anti-DDoS attack, Icmp-echo attack Loop Protect ERPS |
| System Management | CLI: Console, Telnet, SSHv1/2 Web-GUI: HTTP, HTTPS SNMP V1/V2c/V3 RMON NTP Diagnostic : Ping Detection, Tracert Detection, Cable Detection Alarm :PMU Alarm ,Port Link Alarm , Loop Alarm ,POE Alarm Support for importing and exporting configuration files Support restore to factory mode |
